Semi-Automatic Biochemistry Analyzer

V35 Semi-automatic Biochemistry Analyzer

V35 Logo.png

  • Our V35 biochemistry analyzer allows programming of 200 different tests alongwith 35 direct test keys

  • Triplicate calibration mode for accuracy

  • Triplicate mode of sampling with mean / SD / CV

  • Air purge between samples to avoid carry over

  • Online graph and OD / storage of reagent blank absorbance

  • V35 optical system works on absorption spectrophotometry

  • Halogen lamp of 12V and filters having wavelength ranging from 340 nm to 670 nm

Fully Automatic Biochemistry Analyzer

V150 Fully Automatic Biochemistry Analyzer

V150 Logo.png

  • Our V150 fully automatic biochemistry analyzer comes with internal computer with 13'' display screen

  • Constant throughput of 150 test per hour

  • V150 biochemistry analyzer water consumption is ≤ 5 liters per hour

  • Liquid level detection / collision protection / automatic washing / Self recovery function

  • V150 biochemistry analyzer has 50 reagents and 25+5 sample positions with on-board refrigeration system

  • LED light source with 8 channels

  • Reaction cuvettes are reusable with replace frequency of 6 months or whenever necessary

V200 Fully Automatic Biochemistry Analyzer


  • Our V200 fully automatic biochemistry analyzer comes with constant throughput of 200 test per hour

  • V200 biochemistry analyzer water consumption is ≤ 4 liters per hour

  • Liquid level detection / collision protection / real time volume check

  • V200 has linear range of absorbance is 0 to 3.8 Abs having halogen light source

  • Check and judge reaction end point, substrate exhaustion, reagent blank absorbance

  • 60 Positions for samples and reagents, refrigerated compartment

  • Reverse optic system with 8 wavelengths

V240 Fully Automatic Biochemistry Analyzer

V240 Logo.png

  • Our V240 fully automatic biochemistry analyzer comes with constant throughput of 240 test per hour

  • V240 has 45 fixed and 45 interchangeable reagent positions

  • V240 has 45 fixed and 45 interchangeablesample positions

  • Water consumption is relatively low, 2-3 liters per hour

  • Liquid level detection / collision protection / automatic washing / self-recovery system

  • V240 has an optical grating system with 16 wavelengths ranging from 340-800 mm

Haematology

VH3300 Haematology Analyzer

​

VH3300 Logo.png

⦁    Our VH3300 has a throughput of 60 samples per hour
⦁    21 parameters with histograms
⦁    Sample volume: whole blood 9.8 µl, prediluted mode 20 µl
⦁    Data storage: 50,000 sample results with histogram
⦁    Electrical impedance method for WBC/RBC/PLT, cyanide free colorimetry for HGB
⦁    Single click maintenance procedure on service menu

VH3300 VET Haematology Analyzer

​

VH330VET Logo.png

⦁    Our VH3300 VET has a throughput of 60 samples per hour
⦁    21 parameters with histograms
⦁    Sample volume: whole blood 9.8 µl, prediluted mode 20 µl
⦁    Data storage: 50,000 sample results with histogram
⦁    Electrical impedance method for WBC/RBC/PLT, cyanide free colorimetry for Hgb
⦁    Single click maintenance procedure on service menu
⦁    Specific animal species selection mode with reference ranges

VH5500 Haematology Analyzer

​

V53 Logo.png



⦁    Our VH53 has a throughput of 60 samples per hour
⦁    25 parameters with 2 histograms and 2 scattergrams
⦁    Mode: CBC, CBC+5DIFF, CBC+5DIFF+RRBC
⦁    Laser scatter flow cytometry, electrical impedance, cyanide free colorimetric method
⦁    Sample volume: CBC 11 µl ,CBC+5DIFF 16 µL CBC+5DIFF+RRBC 16 µL
⦁    Single click maintenance procedure on service menu
⦁    VET version is also available for the same model
⦁    VH5500 AL is the version available with Auto-Loader

SAMYAK FIA Analyser

SAMYAK I FIA Analyser

Fia Samyak Logo.png

⦁    SAMYAK I FIA Analyzer is a Point of Care (POC) Diagnostic instrument using Advanced Fluorescence Principle for detection of various routine and specialized diagnostic markers.
⦁    ID chip based calibration for the individual lots
⦁    Fastest Result : 3min & Max. time for result : 15min
⦁    Packsize : 10T & 25T for all parameters
⦁    Storage : 2-30 deg Celsius
⦁    Largest menu of 90+ parameters on the platform
⦁    2 modes of operation : Standard & Quick
⦁    Minimum to No maintenance required
⦁    Samyak I have parameters like Vit B12, Dengue NS1, Calprotectin, Malaria, Hormones, Cancer markers which are altogether not available on any other single platform.

SAMYAK II FIA Analyser

Image Samyak 2.jpg

⦁    SAMYAK II FIA Analyzer is a Point of Care (POC) Diagnostic instrument using Advanced Fluorescence Principle for detection of various routine and specialized diagnostic markers.
⦁    QR code based calibration for the individual lots
⦁    Fastest Result : 3min & Max. time for result : 15min
⦁    Packsize : 10T & 25T for all parameters
⦁    Storage : 2-30 deg Celsius
⦁    Largest menu of 90+ parameters on the platform
⦁    2 modes of operation : Standard & Quick
⦁    Graph is visible in the instrument itself
⦁    Samyak II have parameters like Vit B12, Dengue NS1, Calprotectin, Malaria, Hormones, Cancer markers which are altogether not available on any other single platform.

VIMEK Product List

VIMEK Product List

VIMEK Logo.png

VIMEK BIONCONCEPT PVT. LTD. provides a extensive range of kits & instruments for various technologies like Biochemistry, Haematology, Serology, Rapid, Immuno-turbidimetry and Fluorescence Immunoassay. Please click the icon to get our full product list of VIMEK BIOCONCEPT P LTD.
